CE/ANSI Cerificate Alloy Steel Or Aluminum Adjuster For Safety Harness
Featured as a critical component for safety harness kit, the minimal strength of the alloy steel adjuster and aluminum adjuster is18KN. No matter it is alloy steel or aluminum adjuster it is CE and ANSI and CSA certified and meet the CE standard EN362-2004, ANSI standard Z359.12-09 and CSA standard Z259.12-16.
Parameters
ITEM NO.: | HD44-1 | HD44-2 | HD45 | HD46-1 | HD46-2 |
DESCRIPTION OF GOODS: | ADJUSTER (CE) | ADJUSTER (CE) | ADJUSTER (CE) | ADJUSTER (CE) | ADJUSTER (CE) |
MATERIAL: | ALLOY STEEL | ALLOY STEEL | ALLOY STEEL | ALLOY STEEL | ALLOY STEEL |
WEIGHT: | 56/60G | 41G | 54G | 44G | |
WIDTH: | 45/50MM | 50MM | 45MM | 45MM | |
STRENGTH: | 22.2KN | 22.2KN | 18KN | 18KN |
ITEM NO.: | HD47-1 | HD47-2 | HD48-1 | HD48-2 | HD49 |
DESCRIPTION OF GOODS: | ADJUSTER (CE) | ADJUSTER (CE) | ADJUSTER (CE) | ADJUSTER (CE) | ADJUSTER (CE) |
MATERIAL: | ALLOY STEEL | ALLOY STEEL | ALLOY STEEL (INSULATED) | ALLOY STEEL (INSULATED) | ALLOY STEEL |
WEIGHT: | 30G | 19G | 58G | 43G | 136G |
WIDTH: | 45MM | 45MM | 45MM | 45MM | 45MM |
STRENGTH: | 18KN | 18KN | 18KN | 18KN | 18KN |
SPECIAL | MINIMUM 9KV DIELECTRIC RESISTANCE | MINIMUM 9KV DIELECTRIC RESISTANCE |
ITEM NO.: | HD50 | HD51 | HD52 | HD53 | HD54 |
DESCRIPTION OF GOODS: | ADJUSTER (ANSI) | ADJUSTER (CE) | ADJUSTER (CE) | ADJUSTER (CE) | ADJUSTER (CE) |
MATERIAL: | ALLOY STEEL | ALUMINIUM | ALLOY STEEL | ALUMINIUM | ALLOY STEEL |
WEIGHT: | 83G | 72G | 89G | 43G | 47G |
WIDTH: | 45/50MM | 45MM | 45MM | 30MM | 30MM |
STRENGTH: | 18KN | 8KN | 18KN | 18KN | 18KN |
Featured as a critical component for safety harness kit, the minimal strength of the alloy steel adjuster and aluminum adjuster is18KN. No matter it is alloy steel or aluminum adjuster it is CE and ANSI and CSA certified and meet the CE standard EN362-2004, ANSI standard Z359.12-09 and CSA standard Z259.12-16. The adjuster is widely used to adjust length of thigh strap,chest strap and shoulder strap for fall arrest safety harness.It has been exported to more than 85 countries and regions throughout the world in Europe, America, Mid-east area, Australia, Southeast Asia, Africa etc.
As a component for safety harness, the safety harness adjuster is made of alloy steel or aluminum. Some adjusters for special surroundings, such as insulated safety harness adjuster and dielectric safety harness adjuster, are plastic coated, which can offer a minimum 9kV dielectric resistance. The adjuster differs from each other not only in material, but also in style and surface treatment. Zinc plated, polished; Zinc plated, matte and yellow zinc plated, matte are available for surface finish.
There critical steps to ensure the quality:
Ø Spectrographic analysis
Ensure proper metallurgy content of all raw materials.
Ø Proof load Testing
All safety harness connecting components are 100% proof loaded to 3600IBS/16KN.
Ø Ultimate breaking Load Test
Connecting and adjusting components are batch tested for ultimate breaking strength.
-Connecting components-exceed 5000lBS
-Adjusting components-exceed 4000lBS
Frequently Asked Questions (FAQ)
1. How many color could electroplating?
Answer: we could plating color have: silver, antique silver, brushed silver, roll barrel silver, matt silver, gold, brushed gold, matt gold, rose gold, light gold, 18K gold, metal gun color, bronze color, red copper, brushed antique brass color, paint color, etc.
2. The metal material whether will cause allergy?
Answer: our material is eco-friendly metal zinc alloy, the content of Lead, Cadmium, Mercury, Chromium is very low, the Lead is under 40 Pbm.
3. How I make payment?
Answer: we accept make payment by T/T, Western Union.
4. The payment term is?
Answer: after you place order, please arrange the 30% deposit to us in advance, then we begin to produce, once we finish the mass order, will let you know, then pay 70% balance, we received your payment, will arrange delivery as soon as possible.
